100 Ton Conveyor Full Beam Press for Automatic Die Cutting

At Shuntec, we take pride in delivering advanced automation solutions that enhance productivity and efficiency in your manufacturing processes. Our 100 Ton Conveyor Full Beam Press for automatic die-cutting is designed with precision and reliability in mind, ensuring seamless operation and consistent results. Whether you’re looking to optimize production or streamline your workflow, we’re here to provide the cutting-edge technology you need.

Send Inquiry
Details

Shuntec-A01 PRO custom-made 100 ton conveyor full beam press is a custom-designed automatic continuous die cutting press for our customers from Brazil. The application of the press is for automatic die cutting the automotive interior parts. The Shuntec conveyor full beam press automatic die cutting press is the solution for those who are looking for machines to die cut big batches or shapes of large size. available in a wide range from 30 tons to 350 tons, the full beam presses are the best solutions to cut components for automotive, gaskets, packaging, filters, abrasives, foam, insulating, toys, leather goods, and many other industries.

The conveyor full beam press is a more advanced step into fully automating the cutting of a rolled material or sheets of material. The press can pull material off of a roll and feed it through the throat. This press works with substrates of all types and thicknesses because the conveyor advances with the waste material as well as the cut pieces.

All parameters of the automatic die cutting press including tonnage, stroke, open daylight, and bed sizes can be customized to best meet your requirements.

Custom Features of 100 Ton Conveyor Full Beam Press for Automatic Die Cutting

  • Enclosed hydraulic system
  • 4-Post frame structure, with feeding roller, servo driven belt clamps, and pneumatic-cylinder fixing plates
  • With a custom bed table height 1100 mm above the floor
  • Required cylinder stroke 200 mm; Required maximum daylight 200 mm
  • Effective cutting area 1800*1000 mm
  • Automatic pneumatic die/mold clamping device on the slider platen
  • Mitsubishi or Siemens PLC control
  • 10-inch HMI, easy for setting up the technical recipes for different products
  • Calculated ram speed: Approach 100 mm/s; Detecting 35mm/s; Pressing 10 mm/s; Return 100 mm/s
  • Safety mesh shields on the left & right sides
  • Dual channel safety relay circuit for the safety light curtains
  • Double start buttons on the front and rear operating side
  • Heating & sealing functions are available
Specifications
Frame style Full beam press
Application Automatic die cutting
Tonnage 100 Ton
Driven Source Hydraulic
Ship To / Place of Use Brazil
Power Supply  Three-phase AC 220V 60 Hz
Intended Use Automobile, automotive, gaskets, packaging, filters, abrasives, foam, insulating, toys, leather goods
